Kubus Cold Well (HT)

Visual

Self Help Cold Well (HT).

Features

Self Help Cold Well (HT).
Features.

• Rectilinear flat toughened sneeze guard glass profile is designed to compliment other units within the range.
• Cold fan blown well display features integral energy efficient chilled hydrocarbon refrigeration (HT).
• Self help application.
• Features eye-level gantry mounted digital temperature display and control panel (operator side)
• Can achieve temperatures of 0°C to 5°C (max 27°C ambient 55% relative humidity).
• Product illumination is from diffused LED lighting (4000 Kelvin) in a rectangular profile gantry.
• Integral automatic condensate water evaporation eliminates the need for site drainage.
• 24-hour operation as standard.
• Optional compatibility to Dixell & Modbus RTU network store food monitoring systems.
• Superstructure in bright polished steel and aluminium profile
• Supplied with 2 m lead for connection to a single 13 Amp socket (13A 230V 50 Hz).
• Optional non standard airflow available.
• Refrigeration condensing unit is housed in an under slung self contained cradle.
• Self help application – can be factory  converted to assisted service by addition of full height glass screen and end glass (see model below).
• Features ‘tamper proof’ temperature control facility.
• Modular removable deck plate system for easier cleaning and maintenance.

Food Types

Self Help Cold Well (HT).
Food Display Types.

Drinks (Well Area): Still & carbonated, bottled, canned or carton, water, dairy, lemonade, wine, beer, lager, fruit juice & health drinks.

Food (Well Area): Sandwiches, baguettes, rolls, barm cakes salad, pasta, cheese snacks, cream cakes & pastries, cakes, yoghurt, fruit in juice & fruit

Dimensions

Self Help Cold Well (HT).
Dimensions.

• (HT) = R290 Refrigerant.
• Control panel to ‘operator side’ of gantry. If controls are required on customer side, please state ‘Controls to customer side’ when ordering.

Downloads

General Layout Drawings.
Kubus Self Help Cold Wells (HT).

General Layout Drawings.
Non Standard Airflow Options (Cold Displays).

Fitting Instructions & User Manual.
Kubus Self Help Cold Wells (HT).

Visual

Assisted Service Cold Well (HT).

Features

Assisted Service Cold Well (HT).
Features.

• Rectilinear flat toughened full height front sneeze guard & side glass profile is designed to compliment other units within the Kubus range.
• Cold fan blown well display features integral energy efficient chilled hydrocarbon refrigeration (HT).
• Assisted Service application.
• Features eye-level gantry mounted digital temperature display and control panel (operator side)
• Can achieve temperatures of 0°C to 5°C (max 27°C ambient 55% relative humidity).
• Product illumination is from diffused LED lighting (4000 Kelvin) in a rectangular profile gantry.
• Integral automatic condensate water evaporation eliminates the need for site drainage.
• 24-hour operation as standard.
• Optional compatibility to Dixell & Modbus RTU network store food monitoring systems.
• Superstructure in bright polished steel and aluminium profile
• Supplied with 2 m lead for connection to a single 13 Amp socket (13A 230V 50 Hz).
• Optional non standard airflow available.
• Refrigeration condensing unit is housed in an under slung self contained cradle.
• Features ‘tamper proof’ temperature control facility.
• Modular removable deck plate system for easier cleaning and maintenance.

Food Types

Assisted Service Cold Well (HT).
Food Display Types.

Drinks: Still & carbonated, bottled, canned or carton, water, dairy, lemonade, wine, beer, lager, fruit juice & health drinks.

Food: Sandwiches, baguettes, rolls, barm cakes salad, pasta, cheese snacks, cream cakes & pastries, cakes, yoghurt, fruit in juice & fruit

Dimensions

Assisted Service Cold Well (HT).
Dimensions.

• (HT) = R290 Refrigerant.
• Control panel to ‘operator side’ of gantry. If controls are required on customer side, please state ‘Controls to customer side’ when ordering.

Downloads

General Layout Drawings.
Kubus Assisted Service Cold Wells (HT).

General Layout Drawings.
Non Standard Airflow Options (Cold Displays).

Fitting Instructions & User Manual.
Kubus Assisted Service Cold Wells (HT).
